SOUNDMAX SM-SA602

Features

· Class ''AB'' Technology MOSFET PWM Power Supply.

Remote turn-on of the amplifier via car radio

· Continuously Variable 12dB/Octave High Pass & 12dB/Octave Low Pass Crossover.

· Enhanced Bass Boost 0/12dB @50Hz

· Regulator for input sensitivity

· Bridgeable 2-/1-channel & Tri-mode

· Silver Plated RCA & Power, Speaker Terminal.

· Soft Start & Muting.

· Capsulated screw terminals of loudspeaker and power supply

· Overload, Thermal, Short Circuit Protection.

· Power & Protection indicator.

Precautions: Read First!

· If after reading the direction you feel uncomfortable about installing the amplifier in your car, or not

equipped or competent to do so, you should have the amplifier installed by an authorized installer. It's your

car!

· Negative battery terminal must be disconnected before any electrical connections are made.

· Be sure choosing a location that provides substantial ventilation for the amplifier.

· The most preferred locations would be in your car's trunk, under the front seats or on the back wall of a

truck.

· The location chosen should provide at least 2" of clearance above the amplifier for adequate ventilation.

· If the amplifier is to be mounted vertically be sure that it is in a place where adequate air will flow along the

length of its heat sink fins for cooling.

· NEVER mount the amplifier up side down, this will cause the heat to rise back into the amplifier causing

thermal shutdown or possible permanent damage.

· NEVER mount the amplifier in a location that is subject to direct sunlight or exposed to moisture.

· Be sure to mount the amplifier to a strong, solid surface which will not give way under the stress of

· a sudden stop or accident.

· Make sure that the mounting screws will not penetrate the gas tank, brake and fuel lines, wiring or other

critical parts of your car when installed.
