14-6 STEERING

Steerin g Stem

Stem, Stem Bearing Removal

•

Remove:

Windsh

ield and Bracket (see Frame chapter.)

Inner Cover (see Frame chapter.)

Fairing and Bracket ( see Frame chapter.)

Front W

heel (see Wheels/Tires chapter.)

Handlebar (see Handlebar Removal.)

Steering Stem Head Bolt Plug

Steerin

g Stem Head Bolt [A] and Washer

Steering Stem Head

•

Remove the brake hose clamp bolt [A] and take the hose

[B] off the steering stem [C].

•

Remove the front fork (see Suspension chapter).

•

Bend the claw washer tabs [A].

•

Pushing up the stem base, and remove the steering stem

locknut [B] and claw washer [C].

Stem Cap [D]

•

Remove the steering stem nut [A].

Special Tool - Steering Stem Nut Wrench: 57001–1100 [B]

•

Remove the stem cap.

•

Remove the upper stem bearing inner race.
