16-82 ELECTRICAL SYSTEM
Junction Box
Starter Circuit/Headlight Relay Inspection
•
Remove the junction box (see Junction Box Fuse Circuit
Inspec
tion).
•
Check conductivity of the following numbered terminals
by connecting the hand tester and one 12 V battery to the
junct
ion box as shown.
○
Refer to the Junction Box Internal Circuit.
If the tester does not read as specified, replace the junc-
tion
box.
Special Tool - Hand Tester: 57001–1394
Relay Circuit Inspection (with the battery disconnected)
Tester Tester
Connection Reading (Ω)
7-8
∞
7-13
∞
(+) (–)
Headlight
Relay
13 - 9
Not ∞ *
9-11
∞
12 -13
∞
(+) (–)
13 - 11
∞
(+) (–)
Starter
Circuit
Relay
12 - 11
Not ∞ *
(*): The actual reading varies with the hand tester used.
(+): Apply tester positive lead.
(–): A pply tester negative lead.
Relay Circuit I nspection (with the battery connected)
Battery Tester Teste r
Connection (+) (–) Connection Reading (Ω)
Headlight
Relay
9–13 7–8 0
Starter
Circuit
Relay
11–12
(+) (–)
13 – 11
Not ∞ *
(*): The actual reading varies with the hand tester used.
(+): Apply tester positive lead.
(–): A pply tester negative lead.
