5 Getting started
1. Getting started
When unpacking please check you have the following items. If any are missing or damaged, please
contact the place of purchase for a replacement.
Some of the accessories may vary from region to region.
Consider keeping the box and packaging in storage for use in the future when you may need to transport
the monitor. The fitted foam packing is ideal for protecting the monitor during transport.
BenQ LCD Monitor Monitor Controller
Controller Dock
(with a suction cap inside)
Quick Guides and CD-ROM
Power Adapter Power Cord USB Cable
Signal Cable: D-Sub
(optional)
Signal Cable: DVI-D DVI-I to D-Sub Adapter Ambient Light Shield (optional)
