Benq FP992 [7/54] Back view 2 locations of plugs sockets
![Benq FP992 [7/54] Back view 2 locations of plugs sockets](/views2/1122425/page7/bg7.png)
7 Getting to know your Monitor
Back View (2): Locations of plugs & sockets
1. Power AC input jack 2. DVI-D connector
3. D-Sub connector
1
2
3
