Connection and setup

Cable Installation

Before the installation and use, please read carefully the relevant content in “Warning

and Safety instructions”.

1. Take out the TV from the wrapping package and put it in a drafty and flat place.

NOTE:

¾ When you plug or unplug the TV, computer or other equipments, you must make

sure that the AC power has been already shut down;

¾ When unplugging the power cable or signal cable, please hold the plug (the insulated

part), do not draw the body of the cable.

2. The RF output terminal can be connected with the RF input port of the TV.

3. The output AV terminal of DVD can be connected with the AV input port of the TV

through AV cable.

4. The output COMPONENT(YPbPr) terminal of DVD can be connected with the

COMPONENT(YPbPr) input port of the TV through AV cable.

5. Connect one end of the VGA cable with the VGA port on computer, connect the other

end of the VGA cable with the VGA port on the TV, and tighten the bolts clockwise on

the each end of VGA cable.

NOTE:

¾ While connecting the 15-pin VGA, please do not insert the plug overexertedly, for

fear the pin might be broken.

6. Connect one end of the HDMI cable with HDMI output port, connect the other end of

the HDMI cable with the HDMI port on the TV.

NOTE:

¾ While connecting the HDMI, please aim at carefully, do not insert overexertedly, for

fear the pin might be broken.

7. Check and make sure that all AV cables are connected with the corresponding ports

correctly.

NOTE：

power input port with the AC power out of the above range.

¾ Please hold the insulated part of the plug when you are unplugging the power cable,

do not touch directly the metallic part of the cable.

8. Connect the AC power cable with 100-260V AC power supply.

¾ The range of power input for the TV is 100-260V/50Hz, 60Hz, do not connect the TV

NOTE:

¾ COMPONENT and AV can not be used at same time for they share of one audio

channel.
