Philips FWP3100D [19/21] Product information
![Philips FWP3100D [19/21] Product information](/views2/1127598/page19/bg13.png)
20 EN
8 Product
information
Note
Product information is subject to change without prior
notice.
?
&
Rated Output Power 300 W RMS Max
Power
35 Hz - 20 kHz, - 3 dB
Signal to Noise Ratio > 70 dB
;"Q
Tuning Range 87.5 - 108 MHz
Tuning grid 100 KHz
Sensitivity - Mono, 50 dB
S/N Ratio
18 - 22 dBf
Total Harmonic
Distortion
> 2.0 %
Signal to Noise Ratio > 50 dB
Speakers
Speaker Impedance Treble: 6 ohm
Bass: 4 ohm
General information
AC power 220 - 240V ~,
50/60Hz
Operation power
consumption
44 W
USB direct Version 2.0/1.1
Dimensions
(W x H x D)
704 x 385 x 364 mm
Weight
- With Packing
- Main Unit
16.66 kg
13.62 kg
USB playability information
Compatible USB devices:
USB1.1)
card reader to work with this unit)
Supported formats:
FAT32 (sector size: 512 bytes)
MP3 bit rate (data rate): 32-320 Kbps
and variable bit rate
Directory nesting up to a maximum of
8 levels
Number of albums/ folders: maximum
255
Number of tracks/titles: maximum 999
ID3 tag v2.0 or later
File name in Unicode UTF8 (maximum
length: 128 bytes)
Unsupported formats:
Empty albums: an empty album is an
album that does not contain MP3/
the display.
For example, Word documents (.doc)
are ignored and not played.
Содержание
- User manual 1
- Additional features 2
- Adjust sound 2
- Contents 2
- Get started 2
- Important 2
- Listen to radio 2
- Product information 2
- Troubleshooting 2
- Your mini hi fi system 2
- Hearing safety 4
- Mains fuse 4
- Introduction 7
- What s in the box 7
- Your mini hi fi system 7
- A mic 1 mic 2 connect microphones 8
- B bass adjust the bass level of the connected microphone range 5 to 5 8
- C treble adjust the treble level of the connected microphone range 5 to 5 8
- D dbb turn on off dynamic bass enhancement 8
- E dsc select a preset sound setting 8
- F max sound turn on off instant power boost 8
- G volume knob adjust speaker volume 8
- Overview of the main unit 8
- Overview of the remote control 9
- Connect power 11
- Get started 11
- Install remote control battery 11
- Switch to standby mode 12
- Turn demo mode on off 12
- Turn on 1 12
- Basic play operations 13
- Charge the ipod iphone 13
- Compatible ipod iphone 13
- Listen to the ipod iphone 13
- Load the ipod iphone 13
- Play from ipod iphone 13
- Basic play operations 14
- Listen through headphone 14
- Play from usb 14
- Play options 14
- Listen to radio 15
- Select a preset radio station 15
- Store radio stations 15
- Tune to radio stations 15
- Adjust sound 16
- Adjust speaker volume 16
- Boost sound power 16
- Enhance bass 16
- Mute sound 16
- Select a preset sound effect 16
- Select a sound effect 16
- Select an audio output mode 16
- Additional features 17
- Play audio from an external device 17
- Speak or sing through the hi fi system 17
- Adjust decoration light 18
- Enjoy simultaneous play 18
- General information 19
- Product information 19
- Speakers 19
- Usb playability information 19
- Troubleshooting 20
