ProDigit Mini

LCD SCREEN ICONS

BUTTON FUNCTION

1) ON/REF/OFF

Press once to turn the LCD display screen on. Press the button again to set current anglу to zero, REF icon will be displayed to indicate

relative angle measurement mode. Long press to turn off the LCD.

2) HOLD/SOUND

Press once to enter the HOLD function and for the “H” icon be displayed, press once again to release hold function.

Long press the button for 3 seconds to activate sound function, shows. Beeper will sound at level (0°) and plumb (90°). Long

press again to turn off the sound, disappears.

The sound function utilizes a series of beeps that incerase in tempo as it approaches 0 and 90 degrees and eventually reaching a con-

stant tone at exactly 0 and 90 degrees.

3) mm/m%in/ft/LIGHT

Converts angles to different units. Press once to change the display units from degrees (°) to mm/m, to percent slope (%), to pitch

Replace batteries when the Battery Power Icon is flashing. Only flashing when voltage is below 2.2 V.

Sound/Beeper Icon - this icon appears on the screen when the beeper function is activated.

Indicates that the level is working in relative angle mode.

This icon appears on the screen when the HOLD function is activated.

Indicates that the digital level is calibrating for one direction.

Indicates that the digital level is calibrating for another direction.
