Section 03 ELECTRONIC MANAGEMENT SYSTEMS
Subsection 04 (MONITORING SYSTEM AND FAULT CODES)
FAULT
CODE
MODULE DESCRIPTION POSSIBLE CAUSE SERVICE ACTION
P0545
ECM
Exhaust gas
temperature sensor
shortedtoground
Damaged sensor,
damaged circuit wires,
damaged connector or
damaged ECM output
pins
Check for appro
ximately 2280
to 2736 ohms at temperature of
19 to 21°C (66 to 70°F) between
system circui
ts A-H4 and A-J4.
Refer to the Service Manual for more
details.
P0546
ECM
Exhaust gas
temperature sensor
open circuit or
shortedtobattery
Damaged sensor,
damaged circuit wires,
damaged connector or
damaged ECM output
pins
Check for approximately 2280
to 2736 ohms at temperature of
19 to 21°C (66
to 70°F) between
system circuits A-H4 and A-J4.
Refer to the Service Manual for more
details.
P0560
ECM
Battery voltage not
plausible
Battery failure, rectifier
failure, damaged circuit
wires, battery terminal
connection, damaged AC
generator or damaged
connectors
Check fuses 15 (refer to
WIRING
DIAGRAM
).
Check ground continuity to the
engine block.
Refer to th
e Service Manual for
more details.
P0562
ECM
Battery voltage too
low
Battery failure, rectifier
failure, damaged circuit
wires, battery terminal
connection, damaged AC
generator or damaged
connectors
Check fuse
s 15 (refer to
WIRING
DIAGRAM
).
Check ground continuity to the
engine blo
ck.
Refer to the Service Manual for
more details.
P0563
ECM
Battery voltage too
high
Battery failure, rectifier
failure or battery terminal
connection
Check for regulator-rectifier failure.
Refer to the Service Manual for more
details.
P0564
Cluster Cruise switch fault
Thecruiseswitchis
shorted
or activated more
than 60 seconds
Verify the cruise switch if it is normally
open and close when activated.
P0606
ECM ECM ADC f
ault
Damaged
ECM
Replace
ECM.
P060D
ECM
TAS (Throttle
Accelerator sensor)
synchr
onization error
Damaged sensor,
damaged circuit wires,
damaged connector or
damaged ECM pins
Check system circuits B-E1, B-K1,
B-K3, B-
A3, B-B3, B-J3.
Check for 0 volt on sensor connector
pin B & E.
Check fo
r 5 volts on sensor connector
pin A & D.
Check for 0.5 to 3 volts on sensor
connec
tor pin F and 0.25 to 1.5 on C.
Refer to the Service Manual for more
details.
P060E
ECM
Throttle Actuator
- Controller Fault-
digit
al position control
exceeds limit
P0610
ECM
Variant coding fault
P0629
Cluster
Fuel sensor
disconnected fault
Damaged sensor,
damaged circuit wires,
damaged connector or
damaged ECM output
pins
Check for 2.6 ohms (full tank) to 93.6
ohms (
empty tank) between pin C
and pin D at the fuel pump connector.
Check system circuit at the gauge Pin
2and
3 (refer to
WIRING DIAGRAM
).
smr2009-029 205
