Section 03 ELECTRONIC MANAGEMENT SYSTEMS
Subsection 04 (MONITORING SYSTEM AND FAULT CODES)
This will reset the appropriate counter(s) and will
also record that the problem has been fixed in the
related module memory.
SPECIFIC FAULT CODES
Several Fault Codes are Active at once
If this occurs, check the following:
– Check the 30 A fuses in fuse box 2.
– Check the bus bar condition and connections in
fuse box(es).
– Check the diagnostic connector for the pres-
ence of water or corrosion.
– Check the CAN wires.
Fault Code C2121, C2221
iBR or iS application parameters corrupted
(backup no. 1 or no. 2). This fault may occa-
sionally appear as occurred. It happens when
power to the module is cut before the module
normally completed its shutdown. Normal op-
eration is not affected. If it occurs often, check
supply voltage to module.
Fault Code C2122, C2222
iBR or iS last session interrupted. This fault may
occasionally appear as occurred. It occurs when
power to the module is cut before the module nor-
mally completed its shutdown. Normal operation
is not affected.
Fault Code C2130, C2150, C2233,
C2250
iBR or iS motor or system current software
breaker. Motor or module current too high. This
fault may occasionally appear as occurred. Nor-
mal operation is not affected. If it the count is
high, check the moving mechanism of the system
if it is stiffer than normal to operate.
Fault Code C2232
Motor open. If suspension operates when using
the Up/Down s, the suspension will operate nor-
mally when riding even if this fault is active. In
this case, the fault can be ignored. The fault will
be set to "occurred" when the iS module will be
shut down. If suspension does not operate when
using the Up/Down s, refer to
SUSPENSION (iS)
subsection.
Fault Code U0129
CAN communication error between ECM and iBR
modules or iBR CAN message timeout or validity.
This fault may occasionally appear as occurred.
Normal operation is not affected. If it the count
is high, check the related components.
Fault Code P0562
Battery voltage too low. It occurs when both bat-
tery voltage and engine RPM conditions are met.
See chart.
BATTERY VOLTAGE ENGINE SPEED
Lower than 6.5 Vdc Lower than 1280 RPM
Lower than 11.8 Vdc
Greater tha
n 1280 RPM
Fault Code P0563
Battery voltage too high. It occurs when battery
voltage is above 16 Vdc when engine is running.
Refer to
CHARGING SYSTEM
.
Fault Code U016A
Loss of vehicle speed. This fault may occasion-
ally appear as occurred. Normal operation is not
affected. If it the count is high, check the related
components.
Fault Code U0300
Incorrect ECM or information center for the en-
gine. Installed part is not appropriate for the ve-
hicle. Engine will crank but will not start. Refer
to
PARTS CATALOGS
for proper part according to
vehicle.
Fault Code U16A1, U16A2, U16A3,
U16A4, U16A5
Cluster or iBR CAN timeout error-missing CAN ID
xxxh. This fault may occasionally appear as oc-
curred. Normal operation is not affected. If it the
count is high, check the related components.
Fault Code U401, U0457
ECM or cluster CAN message timeout or validity.
This fault may occasionally appear as occurred.
Normal operation is not affected. If it the count
is high, check the related components.
192 smr2009-029
