Section 03 ELECTRONIC MANAGEMENT SYSTEMS
Subsection 04 (MONITORING SYSTEM AND FAULT CODES)
FAULT CODE TABLE
FAULT
CODE
MODULE DESCRIPTION POSSIBLE CAUSE SERVICE ACTION
B2210
Cluster
Left keypad fault
(switch kept activated
more than 60
seconds)
Problem with left keypad
The switch may be defective, verify the
functionality of the switch or the wires.
Refer to the Shop Manual for switch
diagnosis/testing procedure.
B2211
Cluster
Suspension UP/
DOWN switches
shortedtoground
fault
Problem with left keypad
Look for pin B if shorted to ground or
pin C.
B2212
Cluster
Suspension UP/
DOWN switches
disconnected fault
Problem with left keypad
Look for pin B if disconnected
topin14onthecluster.
Look for pin C if disconnected to
pin15onthecluster.
B2213
Cluster
VTS UP/DOWN
switches shorted
to ground fault
Problem with left keypad
Look for pin A if shorted to ground or
pin C.
B2214
Cluster
VTS UP/DOWN
switches
disconnected fault
Problem with left keypad
Look for pin A if disconnected
topin13onthecluster.
Look for pin C if disconnected to
pin15onthecluster.
B2220
Cluster
Right keypad fault
(switch kept activated
more than 60
seconds)
Problem with right
keypad
The switch may be defective, verify the
functionality of the switch or the wires.
Refer to the Shop Manual for switch
diagnosis/testing procedure.
B2221
Cluster
MODE/SET switches
shortedtoground
fault
Problem with right
keypad
Look for pin B if shorted to ground or
pin C.
B2222
Cluster
MODE/SET switches
disconnected fault
Problem with right
keypad
Look for pin B if disconnected
topin17onthecluster.
Look for pin C if disconnected to
pin18onthecluster.
B2223
Cluster
UP/DOWN switches
shortedtoground
fault
Problem with right
keypad
Look for pin A if shorted to ground or
pin C.
B2224
Cluster
UP/DOWN switches
disconnected fault
Problem with right
keypad
Look for pin B if disconnected
topin16onthecluster.
Look for pin C if disconnected to
pin 18 on the cluster
C0042
iBR
Brake Lever Sensor
(BRLS) signals A
open/shorted to
ground
Damaged sensor,
damaged circuit wires,
damaged connector
or damaged iBR pins.
Fault detected when
the engine is running or
stopped
Check system circuits C03-6pos and
C01-12pos.
Check for 0.5 to 3 V on pin F
and0.25to1.5onpinC.
smr2009-029 193
