Section 03 ELECTRONIC MANAGEMENT SYSTEMS
Subsection 04 (MONITORING SYSTEM AND FAULT CODES)
FAULT
CODE
MODULE DESCRIPTION POSSIBLE CAUSE SERVICE ACTION
C0043
iBR
Brake Lever Sensor
(BRLS) signals B
open/shorted to
ground
Damaged senso
r,
damaged circuit wires,
damaged connector
or damaged iB
Rpins.
Fault detected when
the engine is running or
stopped
Check system circuits C03-6pos and
C01-12pos.
Checkfor0.5to3VonpinFand
0.25 to 1.5 on pin C.
C0073
iBR Torque request failure
ECM software failure
Perform ECM software update if
available or
replace ECM.
C2100
iBR
Sensors calibration is
corrupted
Incompatible firmware or
memory failure
Replace iBR unit.
Refer to the
Service Manual for
more details.
C2100
iBR Actuator movement
The iBR gate cannot
move to the desired
position.
Clean and ch
eck for damage in
theiBRgateandnozzlearea.
Refer to the Service Manual for more
details.
C2101
iBR
Actuator movement
warning
The iBR gate cannot
move to the desired
position within expected
time
Clean and check for damage in
the iBR gat
e and nozzle area.
Refer to the Service Manual for more
details.
C2110
iBR
iBR gate p
osition
sensor error
iBR malfunction
Replace iBR unit.
Refer to the Service Manual for
more deta
ils.
C2110
iBR
Angle position sensor
warning
iBR malf
unction
Replace iBR unit.
Refer to
the Service Manual for
more details.
C2110
iBR iBR overheat
iBR cooling system
failure.
iBR unit failure
Check iB
R cooling circuit.
Replace iBR unit.
Refer to the Service Manual for
more det
ails.
C2110
iBR
Monitoring CPU
message time out
or validity
iBR malfunction
Perform an iBR software update
if avai
lable.
Replace the iBR unit.
Refer to the Service Manual for
more d
etails.
C2110
iBR
Monitoring CPU limp
force
iBR malfunction
Perform an iBR software update
if ava
ilable.
Replace the iBR unit.
Refer to the Service Manual for
more
details.
C2120
iBR
Application calibration
is co
rrupted
Incompatible firmware or
memo
ry failure
Perform an iBR software update
if av
ailable.
Replace the iBR unit.
Refer to the Service Manual for
mor
e details.
C2121
iBR
App
lication
parameters corrupted
(backup no. 1
or
no. 2)
Battery power lost or
memory failure
Perform an electrical system shut
dow
nload to clear fault.
Verify starting and charging system
circuits.
Re
fer to the Service Manual
for more details.
194 smr2009-029
