Section 03 ELECTRONIC MANAGEMENT SYSTEMS
Subsection 04 (MONITORING SYSTEM AND FAULT CODES)
FAULT
CODE
MODULE DESCRIPTION POSSIBLE CAUSE SERVICE ACTION
C2122
iBR
Last session
interrupted
Unexpected battery
power lost
Perform an ele
ctrical system shut
down and clear fault.
Verify starting and charging system
circuits.
Refer to the Service Manual
for more details.
C2130
iBR
Motor current
software breaker
Motor current too high
Clean and check for damage in
theiBRgateandnozzlearea.
Refer to the S
ervice Manual for more
details.
C2131
iBR
iBR DC motor shorted
to ground or
12 V
iBR motor failure.
iBR motor wires damaged
Check iBR ci
rcuit A and B.
Refer to the Service Manual for
more details.
C2142
iBR
Brake Lever Sensor
(BRLS) signals A
shortedtobattery
Damaged sensor,
damaged circuit wires,
damaged co
nnector
or damaged iBR pins.
Fault detected when
the engine
is running or
stopped
Check system circuits C03-6pos and
C01-12pos.
Check for 0.5 to 3 V on pin F and
0.25 to 1.5 on pin C.
C2143
iBR
Brake Lever Sensor
(BRLS) signals B
shortedtobattery
Damaged s
ensor,
damaged circuit wires,
damaged connector
or damag
ed iBR pins.
Fault detected when
the engine is running or
stopped
Check system circuits C03-6pos and
C01-12pos.
Check for 0.5 to 3 V on pin F and
0.25 to 1.5 on pin C.
C2144
iBR
Brake Lever Sensor
(BRLS) power shorted
to battery
Damaged sensor,
damage
d circuit wires,
damaged connector
or damaged iBR pins.
Fault d
etected when
the engine is running or
stopped
Check system circuits C03-6pos and
C01-12pos.
Check for 4.5 to 5 volts on sensor
connector pin A & D.
Refer to the Service Manual for
more details.
C2145
iBR
Brake Lever Sensor
(BRLS) power shorted
to ground
Damaged sensor,
damaged circuit wires,
damag
ed connector
or damaged iBR pins.
Fault detected when
the e
ngine is running or
stopped
Check system circuits C03-6pos and
C01-12pos.
Check for 4.5 to 5 volts on sensor
connector pin A & D.
Refer to the Service Manual for
more details.
C2146
iBR
Brake Lever Sensor
(BRLS) signals A/B
reading difference
Dama
ged sensor,
damaged circuit wires,
damaged connector
or d
amaged iBR pins.
Fault detected when
the engine is running or
sto
pped
Check system circuits C03-6pos and
C01-12pos.
Checkfor0.5to3VonpinFand0.25
to1.5onpinC.
C2150
iBR
Sy
stem current
software breaker
iBR input current too high
Clean and check for damage in
th
eiBRgateandnozzlearea.
Refer to the Service Manual for more
details.
smr2009-029 195
