Section 03 ELECTRONIC MANAGEMENT SYSTEMS
Subsection 04 (MONITORING SYSTEM AND FAULT CODES)
FAULT
CODE
MODULE DESCRIPTION POSSIBLE CAUSE SERVICE ACTION
C2151
iBR
System disabled and
need activati
on
System is locked.
Need activati
on
Use B.U.D.S. iB
R unlock function.
Refer to the Service Manual for more
details.
C2155
iBR
Water temperature
sensor overheat
iBR cooling system
failure.
iBR unit failure
Check iBR cooling circuit.
Replace iBR unit.
Refer to the Se
rvice Manual for
more details.
C2161
iBR Low voltage detected
Battery failure, rectifier
failure, damaged circuit
wires, battery terminal
connection, damaged AC
generator or damaged
connectors
Check fuses 15
(refer to
WIRING
DIAGRAM
).
Check ground continuity to the
engine block
.
Refer to the Service Manual for
more details.
C2200 iS
Sensors calibration is
corrupted
Incompatible firmware or
memory failure (Internal
memory fai
lure, return to
supplier)
Defective iS module, replace module
andreturntosupplier.
C2210 iS
Bridge/CP
U
temperature sensor
overheat
Hardware failure or
external heat source
Check for over utilization/heat.
C2220 iS
Applicati
on calibration
is corrupted
Incompatible firmware or
memory failure (B.U.D.S.
should re
pair that)
Program calibration with B.U.D.S.
C2221 iS
Applicat
ion
parameters corrupted
(backup no. 1
or no. 2)
Battery power lost or
memory fa
ilure (Reset
after power-down-up,
clear fault.
If happe
ns often, verify
supply voltage)
Check power wiring and fuse.
C2222 iS
Last ses
sion
interrupted
Unexpec
ted battery
power lost
Check power wiring and fuse.
C2230 iS
Internal motor drive
failur
e
Motor v
oltage feedback
not fitting with the
command
Defective iS module, replace module
andreturntosupplier.
C2231 iS
Motor shorted to
ground/battery
Current leak detected
when the bridge is off
Check suspension actuator pump
wiring.
C2232 iS
Motor open
No current while
activated
Check suspension actuator pump
and/or wiring.
C2233 iS
Motor current
software breaker
Motor
current too high
Check suspension actuator pump.
C2240 iS
Seat position sensor
error Open, Shorted
to Gnd
Sensor not connected
Check
system circuit at iS module
(refer to
WIRING DIAGRAM
).
C2250 iS
System current
softw
are breaker
Battery input current too
high
Check suspension actuator pump.
C225
1
iS
System disabled and
need activation
System is locked
for s
afety.
Need activation
Activate iS using B.U.D.S. activation
function.
196 smr2009-029
