Section 03 ELECTRONIC MANAGEMENT SYSTEMS
Subsection 04 (MONITORING SYSTEM AND FAULT CODES)
FAULT
CODE
MODULE DESCRIPTION POSSIBLE CAUSE SERVICE ACTION
C2252 iS TOPS active
Warning only:
TOPS
detected by the system,
the suspension is disable
while the TOP
Sis"ON"
Check for 12 vol
ts on sensor connector
pin A.
Check continuity for circuits B-H1,
B-H3.
Check fuse 10 (refer to
WIRING
DIAGRAM
) refer to the Service Manual
for more deta
ils.
C2260 iS System under voltage
System under voltage
warning
Check battery and charging system.
P0106
ECM
Intake pressure
sensor out of range
Sensing port dirty or
blocked.
Sensor failure or
unexpected reading
at idle.
Sensor fallen out of
housing or leaking inlet
Check system circuits A-B4, A-G4,
A-H2.
Make sure that the sensor housing is
correctly inserted into the manifold.
Check senso
r connector for:
a) 5 volts on pin 1.
b) 0 volt on pin 2.
c) 0 volt on
pin 3.
Refer to the Service Manual
for more details.
P0107
ECM
Manifold absolute
pressure sensor
shortedtoground
Sensing port dirty or
blocked.
Sensor fa
ilure or
unexpected reading
at idle.
Sensor fa
llen out of
housing or leaking inlet
Check system circuits A-B4, A-G4,
A-H2.
Make sure t
hat the sensor housing is
correctly inserted into the manifold.
Check sensor connector for:
a) 5 volts
on pin 1.
b) 0 volt on pin 2.
c)0voltonpin3.
Refer to t
he Service Manual
for more details.
P0108
ECM
Manifold absolute
pressure sensor open
circuit or shorted to
battery
Sensing
port dirty or
blocked.
Sensor failure or
unexpec
ted reading
at idle.
Sensor fallen out of
housin
g or leaking inlet
Check sy
stem circuits A-B4, A-G4,
A-H2.
Make sure that the sensor housing is
correct
ly inserted into the manifold.
Check sensor connector for:
a) 5 volts on pin 1.
b) 0 volt
on pin 2.
c)0voltonpin3.
Refer to the Service Manual
for mor
e details.
P0112
ECM
Intake manifold
temperature sensor
shortedtoground
Damaged sensor,
damaged circuit wires,
damaged connector or
damaged ECM pins
Check the sensor for approximately
2280 to
2736ohmsat19to21°C
(66to70°F).
Check for approximately 2280 to
2736 o
hmsat19to21°C
(66to70°F)betweenECM
connector pins A-H3 and A-J3.
Refer
to the Service Manual for more
details.
smr2009-029 197
