Section 03 ELECTRONIC MANAGEMENT SYSTEMS
Subsection 04 (MONITORING SYSTEM AND FAULT CODES)
FAULT
CODE
MODULE DESCRIPTION POSSIBLE CAUSE SERVICE ACTION
P0113
ECM
Intake manifold
temperature sensor
open circuit or
shortedtobattery
Damaged sensor,
damaged circuit wires,
damaged connector or
damaged ECM pins
Check the senso
r for approximately
2280 to 2736 ohms at 19 to 21°C
(66to70°F).
Check for appr
oximately 2280 to
2736 ohms at 19 to 21°C
(66to70°F)betweenECM
connector pi
ns A-H3 and A-J3.
Refer to the Service Manual for more
details.
P0116
ECM
Engine temperature
sensor functional
problem
Damaged sensor,
damaged circuit wires,
damaged connector or
damaged ECM pins
Check for debris or blockage in
cooling system.
Check the se
nsor for approximately
2280 to 2736 ohms at 19 to 21°C
(66to70°F).
Check for ap
proximately 2280
to 2736 ohms at 19 to 21°C
(66to70°F)betweenECM
connector
pins A-A1 and A-J2.
Refer to the Service Manual for more
details.
P0117
ECM
Engine temperature
sensor voltage too
low
Damaged sensor,
damaged circuit wires,
damaged connector or
damaged ECM pins
Check for debris or blockage in cooling
system.
Check the
sensor for approximately
2280 to 2736 ohms at 19 to 21°C
(66to70°F).
Check for
approximately 2280
to 2736 ohms at 19 to 21°C
(66to70°F)betweenECM
connect
or pins A-A1 and A-J2.
Refer to the Service Manual for more
details.
P0118
ECM
Engine temperature
sensor voltage too
high
Engine overheated or
damaged sensor
Check for debris or blockage in cooling
system.
Check th
e sensor for approximately
2280 to 2736 ohms at 19 to 21°C
(66to70°F).
Check f
or approximately 2280 to
2736 ohms at 19 to 21°C
(66to70°F)betweenECM
conne
ctor pins A-A1 and A-J2.
Refer to the Service Manual for more
details.
P0122
ECM
TAS (Throttle
Accel
erator sensor) 1
fault (short circuit to
GND)
Damaged sensor,
damaged circuit wires,
damaged connector or
damaged ECM pins
Check system circuits B-E1, B-K1, B-K3.
Check for 0 volt on sensor
conne
ctor pin E.
Check for 5 volts on sensor
connector pin D.
Chec
k for 0.5 to 3 volts on sensor
connector pin F.
Refer to the Service Manual for
more
details.
198 smr2009-029
