English | 13
Bosch Power Tools 2 609 932 794 | (21.3.11)
Adjusting the Speed
The speed of the switched on power tool can be variably ad-
justed, depending on how far the On/Off switch 7 is pressed.
Light pressure on the On/Off switch 7 results in a low rotation-
al speed. Further pressure on the switch results in an increase
in speed.
Adjusting the Screw-in Depth (see figure B)
With the adjustment sleeve 3, the screw-in depth of the screw
head into the workpiece can be preset in 8 locking steps per
full turn. Each step corresponds with a 0.25 mm change of
the screw-in depth.
Turning the adjustment sleeve 3 in clockwise direction results
in a greater screw-in depth; turning in anticlockwise direction
reduces the screw-in depth.
The required setting is best determined by testing.
Working Advice
f Apply the power tool to the screw only when it is
switched off. Rotating tool inserts can slip off.
Guide the screw toward the screwdriving bit 1. The screw is
held in place by the magnet pull of the universal bit holder 10.
Firmly push the tip of the screw into the material to be
screwed until the screwing-depth stop 4 faces against the
workpiece.
Switch the machine on. The screw is screwed into the materi-
al until the adjusted screw-in depth is reached. The drive is
disengaged and the tool holder no longer rotates. Check the
screw-in depth and readjust, if required.
For unscrewing screws, set the rotational direction switch 8
to left rotation and pull off the screwing-depth stop 4 toward
the front without turning the adjustment sleeve.
Working with the screwing-depth stop 4 is also possible when
adapting the screw-in depth.
Belt Clip
With the belt clip 5, the machine can be hung onto a belt. The
user has both hands free and the machine is always at hand.
Maintenance and Service
Maintenance and Cleaning
f Before any work on the machine itself, pull the mains
plug.
f For safe and proper working, always keep the machine
and ventilation slots clean.
If the machine should fail despite the care taken in manufac-
turing and testing procedures, repair should be carried out by
an after-sales service centre for Bosch power tools.
In all correspondence and spare parts order, please always in-
clude the 10-digit article number given on the type plate of
the machine.
After-sales Service and Customer Assistance
Our after-sales service responds to your questions concern-
ing maintenance and repair of your product as well as spare
parts. Exploded views and information on spare parts can al-
so be found under:
www.bosch-pt.com
Our customer service representatives can answer your ques-
tions concerning possible applications and adjustment of
products and accessories.
