Aerofit PLSP [6/12] Plsp parts
![Aerofit PLSP [6/12] Plsp parts](/views2/1135065/page6/bg6.png)
PLSP PARTS
5
D1. 40x80 End Cap (9211-113) pre-installed ................................... [2PCS]
D2. Ø50 End Cap (9211-020) ........................................................... [2PCS]
D3. Ø50 End Cap (9211-074) ........................................................... [6PCS]
D4. End Closure (8130-248) ............................................................. [2PCS]
D5. Rubber Dount (9310-016) ........................................................... [6PCS]
D6. Pinch Cock (OC-06) ................................................................... [2PCS]
D7. Block Rubber (9310-077) ........................................................... [2PCS]
D8. 50x100 END CAP (9211-114) .................................................... [2PCS]
D9. Rubber Insert (9310-076) ........................................................... [4PCS]
D10. Co er Washer (8520-008) ....................................................... [2PCS]
D11. Nylon Bushing (9211-047) ....................................................... [1PCS]
D12. Cap Sleeve (9212-026) ............................................................ [24PCS]
D13. Foam Grip (9162-102) pre-installed ......................................... [2PCS]
D14. End Closure (8890-061) pre-installed ...................................... [2PCS]
D15. Bearing (8510-037) pre-installed ...............................................[4PCS]
D16.Pulley spacer (8530-009)............................................................[2PCS]
D17.End Closure (8130-254)pre-installed...........................................[2PCS]
D1
D2 D3
D4
D5
D6
D7
D8
D9 D10
D11
D12
D13
D14
D15
D16
D17
