PLBC PARTS
5
D1. End Closure (8130-273) pre-installed ........................................
D2. Steel Casing (8530-009) pre-installed .........................................
D3. End Cap (9211-087) ...................................................................
D4. Ø50 End Cap (9211-020) ...........................................................
D5. Ø50 ROUND End Cap (9211-074) ............................................
D6. 50x100 End Cap (9211-014) ......................................................
D7. 50x100 Round End Cap (9211-114) ...........................................
D8. Rubber Dount (9310-016) ...........................................................
D9. Rubber Insert (9310-076) ...........................................................
D10. Block Rubber (9310-077) .........................................................
D11. Pinch Cock (OC-06) .................................................................
D12. Cap Sleeve (9212-026) ............................................................
D13. Co er Washer (8520-001) pre-installed ...................................
D14. Bearing (8510-020) pre-installed ..............................................
D15. Steel Casing (8120-082) pre-installed .......................................
D16. Foam Grip (9162-011) pre-installed .........................................
D17. 60X60 Nylon Bushing (9211-047) ............................................
D18. Hydraulic Seat Adjuster (8830-023) pre-installed ....................
D1
D2
D3
D4 D5
D6
D7 D8
D9
D10
D11
D12 D13
D14 D15
D16
D17
D18
[2PCS]
[
2PCS]
[2PCS]
[2PCS]
[2PCS]
[1PCS]
[4PCS]
[2PCS]
[3PCS]
[2PCS]
[2PCS]
[32PCS]
[4PCS]
[4PCS]
[4PCS]
[2PCS]
[1PCS]
[1PCS]
