Aerofit PLTE [6/12] Plte parts
![Aerofit PLTE [6/12] Plte parts](/views2/1135071/page6/bg6.png)
PLTE PARTS
5
D1. End Closure (8130-131) pre-installed ........................................
D2. Steel Casing (8120-084) pre-installed ........................................
D3. Steel Casing (8530-009) .............................................................
D4. Ø50 End Cap (9211-020) ...........................................................
D5. Ø50 ROUND End Cap (9211-074) .............................................
D6. 40x80 End Cap (9211-113) pre-installed.....................................
D7. 50x100 END CAP (9211-114) ....................................................
D8. Rubber Dount (9310-016) ...........................................................
D9. Rubber Insert (9310-076) ...........................................................
D10. Block Rubber (9310-077) .........................................................
D11. Pinch Cock (OC-06) .................................................................
D12. Cap Sleeve (9212-026) ............................................................
D13. Co er Washer (8520-001) pre-installed ...................................
D14. 38X38 Rubber Pad (9310-001) ................................................
D15. Bearing (8510-003) pre-installed ..............................................
D16. Bearing (8510-020) pre-installed ..............................................
D17. Steel Casing (8120-082) pre-installed......................................
D18. Foam Grip (9162-118) pre-installed .........................................
D19. 60X60 Nylon Bushing (9211-047) ............................................
D20. Hydraulic Seat Adjuster (8830-023) pre-installed ....................
D1
D2 D3
D4 D5
D6
D7 D8
D9
D10
D11
D12 D13
D14 D15
D16
D17
D18
D19
[2PCS]
[4PCS]
[2PCS]
[2PCS]
[2PCS]
[4PCS]
[4PCS]
[2PCS]
[3PCS]
[2PCS]
[2PCS]
[16PCS]
[4PCS]
[2PCS]
[4PCS]
[4PCS]
[4PCS]
[2PCS]
[1PCS]
[1PCS]
D20
