Aerofit PLIP [6/12] Plip parts
![Aerofit PLIP [6/12] Plip parts](/views2/1135072/page6/bg6.png)
PLIP PARTS
5
D1. End Closure (8130-248) ............................................................. [2PCS]
D2. Compression Spring (8840-050) ................................................ [2PCS]
D3. Ø50 End Cap (9211-020) ........................................................... [2PCS]
D4. Nylon Bushing (9211-030) .......................................................... [2PCS]
D5. Ø50 End Cap (9211-074) ........................................................... [6PCS]
D6. 40x80 End Cap (9211-113) pre-installed ..................................... [2PCS]
D7. 50x100 END CAP (9211-114) .................................................... [1PCS]
D8. Rubber Dount (9310-016) ........................................................... [6PCS]
D9. Rubber Insert (9310-076) ........................................................... [4PCS]
D10. Block Rubber (9310-077) ......................................................... [2PCS]
D11. Pinch Cock (OC-06) ................................................................. [2PCS]
D12. Cap Sleeve (9212-026)............................................................ [26PCS]
D13. Co er Washer (8520-008) ....................................................... [2PCS]
D14. Nylon Bushing (9211-047) ....................................................... [1PCS]
D15. 60x60 END CAP (9211-049) .................................................... [1PCS]
D16. Chrome Collar (8890-061) pre-installed ................................... [2PCS]
D17. Bearing (8510-037) pre-installed .............................................. [4PCS]
D18. Foam Grip (9162-102) pre-installed ......................................... [2PCS]
D19.Pulley spacer (8530-009)............................................................[2PCS]
D20.End Closure (8130-254)pre-installed...........................................[2PCS]
D1
D2 D3
D4 D5
D6
D7
D8
D9 D10
D11
D12 D13
D15D14
D16
D17 D18
D19
D20
