Overall

─ 16 ─

Exploded View and Parts List

ITEM NO.

Description QTY

ITEM NO.

Description QTY

1 Left Bottom Frame ASSY 1 20 Short Shaft 1

2 Right Bottom Frame ASSY 1 21 Roller End Plate 2

3 Stangding Frame ASSY 1 22 End Cap，AL, DIA Φ43 1

4 Up Support Frame ASSY 1 23 Socket Head Cap Screw M8*25 2

5 Rotating Frame ASSY 1 24 Socket Head Cap Screw M12*35 8

6 Bracket Frame 1 25 Socket Head Cap Screw M12*85 2

7 Support Frame ASSY 1 26 Socket Head Cap Screw M12*125 3

8 Cross Frame ASSY 1 27 Socket Head Cap Screw M12*135 10

9 Handle Frame ASSY 1 28 Button Head Cap Screw M10*75 10

10 WT Arm Assembly 1 29 Flat Head Cap Screw M10*25 1

11 Leg ASSY 1 30 Flat Head Cap Screw M12*30 5

12 Knee Pad 2 31 Nylon Nut M12 15

13 Leg Pad 2 32 Flat Washer Φ11*Φ20*2 11

14 Roller 1 33 Flat Washer Φ13*Φ24*1.5 38

15 Arm Pad 1 34 Button Head Cap Screw M10*30 1

16 Shaft Φ30*81 1 35 Hex Key S=10 1

17 Shaft Φ30*134 1 36 Hex Key S=8 1

18 Tapered Roller Bearing 2 37 Hex Key S=6 1

19 Domed Aluminium Cap Φ54 5 38 Retaining Collar 2
