─ 5 ─

Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED

Item No. Description Qty

1 Cross Base 1

2 Upright Rear 1

3 Front Base 1

4 Swing Frame 1

5 Stopper Frame 1

6 Adjustable Slide 1

7 Adjustable Pad Frame 1

8 Pop Pin 1

9 Weight Holder 1

10 Bronze Bushing 4

11 Bracket 4

12 Spring Clip 2

13 Plastic Sleeve, 63.5*88.9 2

14 Knee Pad 2

15 Long Sleeve Tube 1

16 Foot Cap, Right 50.8 4

17 Foot Cap, Left 50.8 4

18

Plug, □25.4*76.2

2

19

Plug, □50.8*76.2

2

20 Plastic Sleeve, 50.8*44.5 1

21 Handle Grip 2

22 Spring Collar Plastic Grips 4

23 Pop Pin 1

24 Bumper 1

25 Non Slip Paper 2

26 Seat Pad 1

27 Flat Washer Φ9*Φ16*1.6 8

28 Button Head Cap Screw M10*30 10

29 Button Head Cap Screw M10*70 5

30 Button Head Cap Screw M10*90 1

31 Button Head Cap Screw M10*165 1

32 Nylon Lock Nut M10 7

33 Flat Washer Φ11*Φ23*2 24

34 Short Sleeve Tube 1

35 Button Head Cap Screw M8*25 8

36 Wrench 17-19 1

37 Hex Key S6 1
