Assembly

1. Box content

1. Tiller

2. Blade, right/left

3. Upper handle section

4. Lower handle section x2

5. Handle assembly mounting

6. Plastic guard w/ clips

7. Cable holders

8. Front carrying handle

9. Blade guard, right/left

10. Wheel bushing

11. Depth skid w/ split pin

12. Mounting kit for upper

handle section

13. Manual

2. Fig 1. Attach the wheels. Use the supplied parts shown.

3. Fig 2. Fit the blade guards. Use the supplied bolts.

The left and right guards are different.

4. Fig 3. Fit the blades. Ensure the sharp edges of the blades face forward.

The left and right blades are different.

5. Fig 4. Fit the lower handle section. Use the supplied mountings and bolts.

6. Fig 5. Fit the upper handle section. Use the supplied assembly kit as shown.

7. Fig 6. Fit the cover using four of the supplied clips.

8. Fig 7. Fit the cover behind the lower handle using four more of the supplied clips.

9. Fig 8. Fit the clutch lever. Ensure the lever is level with the lower edge of the handle

as shown.

The cable feeding through upper plastic guard should be fitted to the right side of the

lever.

The cable feeding through the rear plastic guard should be fitted to the left side of the

lever. Ensure the levers are fitted correctly.

Minors are not permitted to operate the machine.

The machine should only be lent to persons who are familiar with its operation.

This user manual must accompany the machine at all times.

The machine may only be operated by persons who are rested, healthy and fit.

If the work is tiring, regular breaks should be taken. Do not use the machine

while under the influence of alcohol.

Factory-fitted control devices, such as the handle-mounted clutch cable, must

not be removed or exposed.

Always check that nuts are correctly tightened before starting.

The machine operator is responsible for ensuring that all parts supplied are

fitted prior to use.
