25 -
Managing stations
Add station to favourites list
3Go to the left column (all stations).
P+/P– Scroll in the pages of the station list if necessary.
6Mark station or select station with the numeric
buttons (
for alphabetical station sorting enter the
initial letter
) which is to be transferred as a
favourite to the favourites list.
OK transfers the station to the favourites list.
The new station is inserted at the end of the
favourites list
.
Proceed in the same manner with additional stations.
Delete station from favourites list
➠ Favourites list (right column) must be selected.
If not, change the list with
4.
6mark station to be deleted.
OK removes the marked station from the favourites list
.
or:
Red button: Activates Clear favourite list.
OK confirms clear list.
Move / change order of stations in the favourites list
➠ Favourites list (right column) must be selected.
If not, change the list with
4.
6
mark station to be moved.
Yellow button: Activates Move station.
6Select insertion position at which the marked
station is to be inserted.
The insertion position can also be selected with
the numeric buttons.
OK to execute the move.
END
INFO
OK
OK
P+
P–
0 9
-
All stations
Select/change favourites
21 EinsPlus
22 ZDFinfokanal
23 ZDFdokukanal
24 ZDFtheaterkan
25 MDR FERNSEH
26 rbb Berlin
27 rbb Brandenburg
28 arte
29 KiKa
30 NDR FS HH
31 NDR FS MV
32 NDR FS NDS
Stations of Favourites 1
13 BR-alpha
14 3sat
15 EinsExtra
16 EinsFestival
17 SAT.1
18 RTL
19 arte
Adopt to favourite list
Select station Next favourite list
Clear favourite lsit Change sorting
Page ↑↓
END
INFO
OK
OK
P+
P–
All stations
Select/change favourites
21 EinsPlus
22 ZDFinfokanal
23 ZDFdokukanal
24 ZDFtheaterkan
25 MDR FERNSEH
26 rbb Berlin
27 rbb Brandenburg
28 arte
29 KiKa
30 NDR FS HH
31 NDR FS MV
32 NDR FS NDS
Stations of Favourites 1
1 Das Erste
2 ZDF
3 WDR Köln
4 Bayrisches FS
5 arte
6 Phoenix
7 BR-alpha
8 3sat
9 EinsExtra
10 EinsFestival
11 SAT.1
12 RTL
Select insert position Select station
Execute move Cancel move
Page ↑↓
0 9
-
