P/T SETTING (pan/tilt head setting)
menu
PAN DIRECTION (NORMAL/REVERSE)
This item is used to select the operations in the horizontal
direction of the pan/tilt head system which are to be
performed by operating the PAN/TILT lever.
When NORMAL is selected as the setting, the pan/tilt head
system moves toward the left when the PAN/TILT lever is
tilted toward the L side, and it moves toward the right when it
is tilted toward the R side.
Conversely, when REVERSE is selected as the setting, the
pan/tilt head system moves in the reverse directions.
Always select REVERSE as the setting when using the
AW-PH300 as the pan/tilt head system in the stand-alone
installation. In this case, when REVERSE is selected as
the setting, the pan/tilt head system moves toward the left
when the PAN/TILT lever is tilted toward the L side, and it
moves toward the right when it is tilted toward the R side.
Conversely, when NORMAL is selected as the setting, the
pan/tilt head system moves in the reverse directions.
TILT DIRECTION (NORMAL/REVERSE)
This item is used to select the operations for the vertical
direction of the pan/tilt head system which are to be
performed by manipulating the PAN/TILT lever.
When NORMAL is selected, the pan/tilt head system moves
upward when the PAN/TILT lever is tilted toward the UP side,
and it moves downward when it is tilted toward the DOWN
side.
Conversely, when REVERSE is selected, the pan/tilt head
system moves in the reverse directions.
Always select REVERSE as the setting when using the
AW-PH300 as the pan/tilt head system for suspended
installation. In this case, when REVERSE is selected, the
pan/tilt head system moves upward when the PAN/TILT
lever is tilted toward the UP side, and it moves downward
when it is tilted toward the DOWN side.
Conversely, when NORMAL is selected, the pan/tilt head
system moves in the reverse directions.
ZOOM DIRECTION (NORMAL/REVERSE)
This item is used to select the zoom movements of the lens
which are to be performed by operating the ZOOM lever.
When NORMAL is selected as the setting, the zoom moves
toward the telephoto side when the ZOOM lever is tilted
toward the TELE side, and it moves toward the wide-angle
side when it is tilted toward the WIDE side.
Conversely, when REVERSE is selected as the setting, the
zoom moves in the reverse directions.
FOCUS DIRECTION (NORMAL/REVERSE)
This item is used to select the focus operations of the lens
which are to be performed by operating the dials on the top
of the PAN/TILT lever and ZOOM lever.
When NORMAL is selected, the focus moves toward the
far-distance side when the dial is turned toward the FAR
side, and it moves toward the near-distance side when it is
turned toward the NEAR side.
Conversely, when REVERSE is selected as the setting, the
focus moves in the reverse directions.
IRIS DIRECTION (NORMAL/REVERSE)
This item is used to select the focus operations of the lens
which are to be performed by operating the dials on the top
of the PAN/TILT lever and ZOOM lever.
When NORMAL is selected for the setting, turn the dial
towards OPEN to open up the iris and towards CLOSE to
close in the iris.
Conversely, when REVERSE is selected as the setting, the
iris moves in the reverse directions.
As the focusing of some lenses moves in reverse, select the
setting which best suits the operator.
SPEED SELECT (PAN)
(HIGH: SLOW/MID/FAST; LOW: SLOW/MID/FAST)
This item is used to select the speed at which the pan/tilt
head system is to operate in the horizontal direction in
response to operation of the PAN/TILT lever.
The speed can be set to SLOW, MID or FAST for the HIGH
mode and also for the LOW mode which are switched using
the SPEED button.
When 1 or 2 has been selected as the SPEED WITH
ZOOM POS. item setting, switching between SLOW, MID
and FAST is not possible.
SPEED SELECT (TILT)
(HIGH: SLOW/MID/FAST; LOW: SLOW/MID/FAST)
This item is used to select the speed at which the pan/tilt
head system is to operate in the vertical direction in
response to operation of the PAN/TILT lever.
The speed can be set to SLOW, MID or FAST for the HIGH
mode and also for the LOW mode which are switched using
the SPEED button.
When 1 or 2 has been selected as the SPEED WITH
ZOOM POS. item setting, switching between SLOW, MID
and FAST is not possible.
SPEED SELECT (ZOOM)
(HIGH: SLOW/MID/FAST; LOW: SLOW/MID/FAST)
This item is used to select the speed at which the lens is
to perform zoom operations in response to operation of the
ZOOM lever.
The speed can be set to SLOW, MID or FAST for the HIGH
mode and also for the LOW mode which are switched using
the SPEED button.
SPEED SELECT (FOCUS)
(HIGH: SLOW/MID/FAST; LOW: SLOW/MID/FAST)
This item is used to select the speed at which the lens is to
perform the focusing operations in response to operation of
the dials on the top of the PAN/TILT lever and ZOOM lever.
The speed can be set to SLOW, MID or FAST for the HIGH
mode and also for the LOW mode which are switched using
the SPEED button.
