Specifications

Genlock input: BNC

Black burst or composite video signal, Tri Sync

Prompter input

(PROMPTER IN): BNC

Through output to PROMPTER connector

Prompter output

(PROMPTER OUT): D-SUB 15-pin

Camera video output

VIDEO: BNC, 75-ohm output

Y: BNC, 75-ohm output

Pr/C: BNC, 75-ohm output

Pb: BNC, 75-ohm output

SDI: BNC

AUX: BNC

Camera, pan-tilt head control: RJ45, RS-422, pan-tilt head control signal output

RP Connecting cable: 10BASE-T straight cable (equivalent to UTP category 5),

max. 1000 meters

Functions/performance: Maximum weight capacity: 15 kg

Tilt range: 300 degrees (approx. ±150 degrees)

The tilt range is subject to restrictions depending on the cable and lens of camera to be

mounted on pan-tilt head.

Pan range: 300 degrees (approx. ±150 degrees)

Maximum operating speed: 45 degrees/sec.

( when the centre of gravity of the units installed on the pan-tilt head has been aligned with

the head’s centre of rotation)

(Maximum operating speed with prompter mounted: 15 degrees/sec.)

Stop accuracy: ±3´

Noise level: Less than NC35 (at less than 30 degrees/sec.)

Ambient operating temperature: –5°C to +45°C

Storage temperature: –20°C to +65°C

Ambient operating humidity: 30% to 90% (no condensation)

Dimensions (WHD): 319416168 mm

Weight: Approx. 10 kg

Finish: AV ivory paint (colour resembling Munsell 7.9Y6.8/0.8)

Weight and Dimensions indicated above are approximate.

Specifications are subject to change without notice.

Supply voltage: AC 220 to 240 V, 50 Hz

Power consumption: 120 W

indicates safety information.
