EPSON Stylus Photo 750 Revision A
Product Description General Description 5
1.2 General Description
1.2.1 Printing
PRINTING METHOD
†
On demand ink jet
NOZZLE CONFIGURATION
†
48 nozzles x 6 (Black, Cyan, Magenta, Yellow, Light Cyan, Light
Magenta)
Figure 1-2. Nozzle Configuration
PRINTING DIRECTION
†
Bi-direction with logic seeking
PRINTING SPEED AND PRINTABLE COLUMNS
†
Character mode
Table 1-1. Printing Speed
** This value is the speed of one print-pass in which the 1/3 of character
matrix is printed.
†
Raster graphics mode
Table 1-2. Raster Graphics Mode
CONTROL CODE
†
ESC/P Raster
†
EPSON Remote command
CHARACTER TABLES
†
2 international character sets
„
PC437 (US, Standard Europe)
„
PC850 (Multilingual)
#1
#48
0.212 m m
(3 /3 6 0 ")
Bk C yan LC M LM
Y sp02
Character Pitch Printable columns LQ speed
10 CPI (Pica) 80 200CPS**
Horizontal
resolution
Printable area Available dot CR Speed
180 dpi 8.26 inch 1488 20 IPS
360 dpi 8.26 inch 2976 20 IPS
720 dpi 8.26 inch 5952 20 IPS
