Cassette operations

Loading a cassette

- Turn the power on.

- Press the OPEN button on the panel. Insert the cassette with the exposed tape side facing right into the

slot. The playback will start automatically.

Play direction reverse

Press both the REWIND and FAST FORWARD buttons on the back of the front panel at the same time to

reverse the play direction of the tape while it is still playing.

When the tape reaches to the end, it reverses automatically and the other side begins to play.

Rewind/ Fast forward

Press the REWIND or FAST FORWARD button on the back of the front panel to fast forward or

rewind the tape.

Stop playback

To stop the playback press the OPEN button to open the panel, then press the EJECT button.

The playback will be stopped, the cassette will be ejected.

Cleaning

Cleaning the cabinet

- Wipe with a soft cloth. If the cabinet is very dampen (not dropping wet) the cloth with a

weak solution of soapy water, and then wipe clean.

Cleaning the heads of tape recorder

- Periodic cleaning of the tape head, capstan and pinch rollers will ensure good reproduction

of music and trouble-free operation.

- Cleaning of the tape head should be done every 20 to 30 hours of operation or when the

high tones have become less clear.

- Clean the tape head, capstan and the pinch rollers with the cotton swab soaked in alcohol.

- Allow the tape head, capstan and pinch rollers to dry before operating.

- Do not touch the tape with your fingers. If it becomes lose wind it back by twisting six-sided

pencil in the cassette reel.
