JVC KD-R707 EE [7/91] Preparation

ENGLISH

7OPERATIONS

Preparation

Canceling the display demonstration and setting the clock

• See also page 17.

Turn on the power.

[Turn] = [Press]

Cancel the display demonstrations

Select “DEMO,” then “DEMO OFF.”

Set the clock

Select “CLOCK” = “CLOCK SET.”

Adjust the hour, then press control dial once to proceed to

adjust the minute.

Select “24H/12H,” then “24 HOUR” or “12 HOUR.”

• To return to the previous menu, press BACK.

Changing the display information

When the power is turned off: The current clock time is displayed if “CLOCK DISP” is set to “CLOCK OFF,”

(see page 17).

When the power is turned on: The display information of the current source changes as follows:

FM/AM/FM-LO Station Frequency = Clock = (back to the beginning)

FM Radio Data

System

Station name (PS) = Station Frequency = Programme type (PTY) = Clock =

(back to the beginning)

CD/USB/USB-IPOD

Audio CD/CD Text: Disc title/performer *

= Track title *

= Current track number

with the elapsed playing time = Current track number with the

clock time = (back to the beginning)

MP3/WMA: Album name/performer (folder name) *

= Track title (file

name) *

= Current track number with the elapsed playing

time = Current track number with the clock time = (back to

the beginning)

If the current disc is an audio CD, “NO NAME” appears.

If an MP3/WMA file does not have Tag information or “TAG DISPLAY” is set to “TAG OFF” (see page 18),

folder name and file name appear.

Not applicable for “USB-IPOD.”

Press and hold until the

main menu is called up.

• Repeat this procedure.
