Roland HP203-ERW [2/2] Hp 201 amazing sound in an attractive cabinet

------------------------------------------------------------------------------------------------------------------------------------

HP-207: The Ultimate in Elegance and Playability

------------------------------------------------------------------------------------------------------------------------------------

The flagship HP-207 features an ultra-realistic 88-key multi-sampled

piano sound under the

control of Roland’s new

PHA II “Ivory Feel” keyboard

with Escapement, along with

key touch adjustable to 100

HP-203: Acoustic Feel, Powerful Digital Features

------------------------------------------------------------------------------------------------------------------------------------

The HP-203 is equipped with an advanced PHA II Keyboard with

Escapement, providing a natural touch and ultra-wide dynamic

response. Roland’s acclaimed

88-key multi-sampled piano

sound is onboard, as is

support for continuous

------------------------------------------------------------------------------------------------------------------------------------

HP-201: Amazing Sound in an Attractive Cabinet

------------------------------------------------------------------------------------------------------------------------------------

With its elegantly designed cabinet (featuring front legs), the HP-201

is an excellent centerpiece to any home. It plays and sounds like a

real piano thanks to its all-new

multi-sampled piano sound

and a PHA II keyboard,

which provides a wide and

expressive touch response.

PHA II: Progressive Hammer Action

------------------------------------------------------------------------------------------------------------------------------------

a natural touch response from pianissimo to fortissimo. In addition,

the HP-series’ acclaimed Escapement feature comes standard on

the HP-207 and HP-203 models.

2-piece structure, which consists of base- and surface-material layers.

This reproduces stability and comfort of a real acoustic-piano keyboard.

HP-203

HP-207

" Stretched Tuning On/Off " Master Tuning 415.3 to 466.2 Hz (adjustable in increments of 0.1 Hz)

" Transpose Key Transpose: -6 to +5 (in semitones), Playback Transpose (with Audio CD/Audio File): -6 to

+5 (in semitones) " Effects 3D (4 Levels), Dynamics (4 Types), Reverb (Off/1 to 10), Key Off Resonance

(only for piano tones, Off/1 to 10), String Resonance (only for piano tones, Off/1 to 10), Damper Resonance

(only for piano tones, Off/1 to 10) [Recorder] " Tracks 3 tracks " Songs Recorder Section: 1 song, Internal

Memory: Max. 99 songs " Note Storage Approx. 30,000 notes " Control Song Select, Play/Stop, Rec,

Previous/Rewinding, Next/Fast-forwarding, Track Mute (Mute Level adjustable), Tempo, Tempo Mute, All

Song Play, Count-in, Count-down, Song Volume, Center Cancel (only for audio playback) " Tempo Quarter

note = 10 to 500 " Resolution 120 ticks per quarter note " Metronome Beat: 2/2, 0/4, 2/4, 3/4, 4/4, 5/4, 6/4,

7/4, 3/8, 6/8, 9/8, 12/8, Volume: 0 to 10, Metronome Sound: 8 types [Internal Memory] " Songs Max. 99

recognition), Soft (half-pedal recognition, function assignable), Sostenuto (function assignable) " Other

Function Panel Lock, V-LINK " Connectors AC inlet, Pedal connector, Input jacks (Front: L/Mono, R Rear:

L/Mono, R), Output jacks (L/Mono, R), USB connector, MIDI connectors (IN, OUT), Phones jack (Stereo) x 2,

External Memory port " Power Supply AC 115 V, AC 117 V, AC 220 V, AC 230 V, AC 240 V (50/60 Hz)

" Power Consumption 70 W " Dimensions With Music Rest: 1387 (W) x 422 (D) x 1036 (H) mm/ 54-5/8

(W) x 16-5/8 (D) x 40-13/16 (H) inches, Without Music Rest: 1387 (W) x 422 (D) x 846 (H) mm/ 54-5/8 (W) x

16-5/8 (D) x 33-5/16 (H) inches " Weight 56 kg / 123 lbs " Accessories Owner's Manual, Roland 60

Classical Piano Masterpieces, Power Cord, Headphone Hook, Music Rest, Music Rest's attachment screws

" Options USB Memory, Floppy Disk Drive: FD-01A, Holder (External CD drive): DH-01

*1 A list of the CD drives that have been tested and found to be compatible is available on the Roland website.

(adjustable in increments of 0.1 Hz) " Transpose Key Transpose: -6 to +5 (in semitones) " Effects Reverb

(10 levels), Dynamics (3 levels, Off), Key Off Resonance (only for piano tones, 8 levels), Damper Resonance

(only for piano tones, 8 levels) [Recorder] " Track 1 track " Song Recorder section: 1 song " Note Storage

Approx. 10,000 notes " Controls Song Select, All Song Play/Stop, Rec " Tempo Quarter note = 10 to 500

" Resolution 120 ticks per quarter note " Metronome Beat: 0/4, 2/4, 3/4, 4/4, 6/4, Volume: 8 levels [Other]

" Internal Songs 65 songs " Rated Power Output 25 W x 2 " Speakers 12 cm x 2 " Control Volume

" Pedals Damper (half-pedal recognition), Soft (half-pedal recognition), Sostenuto " Other Function Panel

Lock, V-link " Connectors AC inlet, Pedal connector, Input jacks (L/Mono, R), Output jacks (L/Mono, R), USB

connector, MIDI connectors (In, Out), Phones jack (Stereo) x 2 " Power Supply AC 115 V, AC 117 V, AC 220

V, AC 230 V, AC 240 V (50/60 Hz) " Power Consumption 48 W " Dimensions with Music Rest: 1387 (W) x

GM2/GS/XG Lite " Max. Polyphony 128 voices " Tones 337 tones (including 8 drum sets, 1 SFX set)

" Temperament 8 types, selectable tonic " Stretched Tuning Off/Preset/User tuning (adjustable in indivisual

notes: -50.0 to +50.0 cent) " Master Tuning 415.3 to 466.2 Hz (adjustable in increments of 0.1 Hz)

" Transpose Key Transpose: -6 to +5 (in semitones), Playback Transpose (with Audio CD/Audio File): -6 to

+5 (in semitones) " Effects 3D (4 Levels), Dynamics (4 Types), Reverb (Off/1 to 10), Rotary Speaker Effect

(only for organ tones, Slow/Fast), 4-band Digital Equalizer, Tone effects (only adjust values), Only for Piano

Tones: Open/close lid (only for piano tones, 7 levels), Hammer Noise (5 levels), Damper Resonance (Off/1 to

10), Damper Noise (Off/1 to 10), Duplex Scale (Off/1 to 10), String Resonance (Off/1 to 10), Key Off Resonance

(Off/1 to 10) [Recorder] " Tracks 3 tracks " Songs Recorder section: 1 song, Internal Memory: Max. 99

songs " Note Storage Approx. 30,000 notes " Control Song Select, Play/Stop, Rec, Previous/Rewinding,

Separately), USB Floppy Disk Drive (Sold Separately) " Playable Software Standard MIDI Files (Format

0/1), Roland Original Format (i-Format), Audio File (WAV 44.1kHz / 16bit Linear Format), Audio CDs (CD-DA)

[Others] " Internal Songs 70 songs + 7 Tone Demo Songs " Rated Power Output 60 W x 2 " Speakers

16 cm x 2, 5 cm x 2 " Display 128 x 64 dots Graphic monocrome LCD (with backlit) " Language English,

Japanese " Lyrics Yes (Built-in Display) " Control Volume, Brilliance, LCD Contrast " Pedal Damper (half-

pedal recognition), Soft (half-pedal recognition, function assignable), Sostenuto (function assignable) " Other

Function Panel Lock, Panel Lid, V-LINK " Connectors AC inlet, Pedal connector, Input jacks (Front :

L/Mono, R Rear: L/Mono, R), Output jacks (L/Mono, R), USB connector, MIDI connectors (IN, OUT), Phones

jack (Stereo) x 2, Ext Memory port " Power Supply AC 115 V, AC 117 V, AC 220 V, AC 230 V, AC 240 V

(50/60 Hz) " Power Consumption 105 W " Dimensions With Music Rest: 1388 (W) x 529 (D) x 1,076 (H)
