Caiman VARIO 60S TWK+ [4/5] Description

Caiman VARIO 60S TWK+ [4/5] Description
Rep
N°
Ref.
Désignation
Description
Qte
200 3002210308
JOUE DE CARTER 8/37 NOIR RAL 9005
Tranmission housing 8/37 black RAL 9005
2
201 0341000059
Joint carter 1/5 Ø62 x Ø25
Seal
2
202 0306050045
ARBRE DE TRAVAIL 37DTS 12.7
Blade shaft 37 teeth 12.7
1
203 0306050016
PIGNON 8 DTS 12.7 SIMPLE cannelé
PIGNON 8 TOOTH 12.7 RIBBED
1
204 0306020026
CHAINE ISO 08B-1 pas 12.7 (78M) "78 maillons RSF (Marquée : ""
CHAIN (78 LINKS RSF) 08B
1
205 0306010037
ROULEMENT 6906 2RS
Ball bearing 6906 2RS
1
206 0306010020
ROULEMENT 6305 2 RS cl: 0
BALL BEARING 6305 2RS
2
207 0306010016
ROULEMENT 6204 2RS EPAULE
SPECIAL BALL BEARING 6204 2RS
1
208 0303000029
ENTRETOISE 3 pts CARTER 8/37
TRANSMISSION SPACER 8/37
1
209 0303000026
ENTRETOISE 34.5x16x9 CARTER 8/37
Transmission spacer
1
210 0300600604
INSERT M6 ROND BORGNE TOLE 1.5/3
Insert M6
2
211 0300210602
ECROU FREIN M 6 Z DIN 985-8
BLOCKING NUT M 6 Z
18
212 0300110604
VIS TORX M6X12 TETE CYLIND BOMB 6 LOBES INTER
Screw Torx M6x12
18
Re
p
N°
Ref.
Désignation
Description
Qte
63 0301040001
CLAVETTE 4.76X4.76X 40 BTS DRO TOL h 9 - XC 48
KEY 4.76X4.76X40 DRO TOL h 9 - XC 48
1
64 0301010014
GOUPILLE CLIPS 10 x 36
CLIP PIN D10 x 36
2
65 0301010013
GOUPILLE CLIPS 8 x 36
CLIP PIN D8 x 36
6
66 0300801401
POIGNEE SERRAGE M14x150 EMBOUT NOIR
HANDLEBAR TIGHTENING LEVER
1
67 0300430801
RONDELLE CONTACT M8 NF E 25511
CONTACT WASHER 8
2
68 0300410602
RONDELLE SPECIALE 6,3X19 X2,5Z
SPECIAL WASHER 6,3 x 19 x 2,5Z
2
69 0300401201
RONDELLE PLATE M 12X27X2.5 Z NFE 25513
PLATE WASHER M 12X27X2.5 Z NFE 25513
1
70 0300400802
RONDELLE PLATE M 8X18X1.5 Z NFE 25513
PLATE WASHER M 8X18X1.5 Z NFE 25513
4
71 0300400301
RONDELLE PLATE 3.2x10x1 Z
Washer M 3.2x10x1 Z
1
72 0300260801
ECROU HM 8 ZEMB CR DIN 6923-8
NUT H M8 Z NOTCHED SHOULDER
4
73 0300260601
ECROU HM 6 ZEMB CR DIN 6923
NUT H M6 Z NOTCHED SHOULDER
3
74 0300211402
ECROU FREIN M14 Z DIN 985-8
Blocking nut M 14 Z DIN 985-8
1
75 0300211201
ECROU FREIN M 12 Z DIN 985/8
BLOCKING NUT M 12 Z
2
76 0300211201
ECROU FREIN M 12 Z DIN 985/8
BLOCKING NUT M 12 Z
1
77 0300211001
ECROU FREIN M 10 Z DIN 985/8
BLOCKING NUT M 10 Z
2
78 0300210802
ECROU FREIN M 8 Z DIN 985/8
BLOCKING NUT HM 8 Z DIN 985/8
5
79 0300210602
ECROU FREIN M 6 Z DIN 985-8
BLOCKING NUT M 6 Z
12
80 0300201002
ECROU H.U. M 10 Z DIN 934
NUT HM 10Z
2
81 0300120404
VIS PT WN 1412 KB 40x14
Screw PT WN 1412 KB 40x14
1
82 0300080610
VIS TRCC 6 X 45/20 Z Din603
SCREW TBCC M6X45 Z
1
83 0300080405
VIS TOLE TETE POELIER D11 POZI Cr 4.2X16 Z
SCREW POZI 4.2X16Z
1
84 0300080404
VIS TOLE TCB 4.8X9.5 DIN 7981
SHEET SCREW TCB 4.8 X 9.5
1
85 0300060502
VIS 5/16 TH 24 UNF LONG 32 Z
SCREW 5/16 TH 24 UNF LG 32
2
86 0300040801
VIS STHC 8 X 16 N BT POINTU DIN 914 45H
SCREW ST HC M8X16 DIN 914 45H
1
87 0300020608
VIS CHC 6 X 12 Z DIN 912 8.8
Screw CHC M6x12z
4
88 0300020605
VIS CHC 6 X 50 Z DIN 912 8.8
SCREW CHC 6 X 50 Z DIN 912 8.8
1
89 0300020604
VIS CHC 6 X 35 Z DIN 912 8.8
Screw CHC M6x35z
1
90 0300011401
VIS H 14 X 90/34 Z CL 8.8 NFE 24014 - ISO 4014
Screw H M14x90-34 z cl 8.8 NFE 24014 - ISO 4014
1
91 0300011206
VIS H M 12x80/30 Z ISO 4014 CL 6.8
SCREW H M 12X80/30 Z ISO4014
1
92 0300011205
VIS H 12 X 60/30 N DIN931/6.8
Screw H M12 x 60 z
1
93 0300011015
VIS HM10 X 30 Z NFEN24017 CL8.8 FST
Screw HM 10x30z FST
1
94 0300011007
VIS H M 10x55/26 Z ISO 4014 cl 6.8
Screw H M 10x55 Z
1
95 0300011003
VIS H 10 X 35 FST Z NFEN 24017
SCREW HM 10X35Z FST
1
96 0300010837
VIS H 8x55 Z EMB CR DIN 6921 CL 6.8 FILETAGE PARTIEL
SCREW H 8x55 Z DIN 6921 NOTCHED SHOULDER CL 6.8
4
97 0300010817
VIS H 8x40 Z EMB CR DIN 6921
SCREW H M8 X 40
4
98 0300010802
VIS H 8 X 45/22 Z DIN931/6.8
Screw H M8 x 45
1
99 0300010610
VIS H 6x20 Z EMB CR DIN 6921
Screw HM 6x20 notched shoulder
1
100 0300010609
VIS H 6x16 Z EMB CR DIN 6921
SCREW HM 6X16 Z NOTCHED SHOULD
8
101 0300010608
VIS H 6 X 12 Z NF EN 24017/6.8
Screw HM6x12
2
