Humminbird Matrix 17 Инструкция по эксплуатации онлайн
Содержание
- Operations manual operations manual 1
- Accessory bus 17 2
- Contact our customer resource center at either 1 334 687 0503 or visit our website at www humminbird com 2
- How sonar works 1 2
- Key functions 14 2
- Powering up the unit 17 2
- Start up options menu 20 2
- Table of contents 2
- Thank you 2
- Thank you for choosing humminbird america s 1 name in fishfinders humminbird has built its reputation by designing and manufacturing top quality thoroughly reliable marine equipment your humminbird is designed for trouble free use in even the harshest marine environment in the unlikely event that your humminbird does require repairs we offer an exclusive service policy free of charge during the first year after purchase and available at a reasonable rate after the one year period for complete details see the separate warranty card included with your unit we encourage you to read this operations manual carefully in order to get full benefit from all the features and applications of your humminbird product 2
- The menu system 18 2
- Views 5 2
- What s on the display 3 2
- Accessories menu tab 48 3
- Alarms menu tab 37 3
- Contact humminbird 55 3
- Matrix fishing system accessories 52 3
- Setup menu tab 39 3
- Sonar menu tab 28 3
- Sonar x press menu 23 3
- Specifications 54 3
- Table of contents 3
- Troubleshooting 49 3
- Dualbeam plus sonar 4
- How sonar works 4
- Quadrabeam sonar 4
- Single beam sonar 4
- Bait ball 5
- Hard bottom 5
- Rocky bottom 5
- Rts real time sonar window 5
- Soft bottom 5
- The matrix fishing system can display a variety of useful information about the area under and adjacent to your boat including the following items 5
- What s on the display 5
- Sonar view 6
- Understanding sonar history 6
- A real time sonar rts window appears on the right side of the display in the sonar view only the rts window always updates at the fastest rate possible for depth conditions and shows only the returns from the bottom structure and fish that are within the transducer beam the rts window plots the depth and intensity of a sonar return see sonar menu rts window 7
- As the depth changes the zoomed view updates automatically to display a magnified image of the bottom the zoom preview box shows where the zoomed view is in relation to the full range view the zoom level or magnification is displayed in the lower left corner and can be changed to suit conditions see sonar x pres 7
- Digital depth is displayed in the upper left hand corner the digital readouts in the sonar zoom view cannot be customized therefore information such as water temperature and voltage are unavailable in the sonar zoom view 7
- Menu zoom level upper and lower zoom depth range numbers indicate the depth of the water which is being viewed 7
- Real time sonar rts window 7
- Sonar zoom view 7
- Sonar zoom view increases the displayed resolution to separate sonar returns that are very close together such as those caused by fish suspended close to the bottom or within structure in zoom view the display is split to show a narrow slice of the full range view on the right and the zoomed view on the left the full range view on the right also contains the zoom preview box that shows what part of the full range view is shown in zoom view on the left the zoom preview box tracks the bottom in the full range view 7
- 83 khz split sonar view 8
- Big digits view 8
- Big digits view provides digital data in a large easy to see format depth is always displayed readouts for temperature speed and triplog information are displayed automatically if the appropriate accessory is connected to the system the triplog shows distance traveled average speed and time elapsed since the triplog was last reset the digital readouts in the big digits view cannot be customized 8
- Dualbeam plus and quadrabea 8
- Split sonar view displays sonar returns from the 83 khz wide beam on the left side of the screen and displays sonar returns from the 200 khz narrow beam on the right side of the screen depth is always displayed in the upper left hand corner you can use the split sonar view to make side by side comparisons between the sonar returns from the 83 khz wide beam and the 200 khz narrow beam 8
- The digital readouts in the split sonar view cannot be customized therefore information such as water temperature and voltage are unavailable in the split sonar view 8
- Bottom presentation 9
- Side beam view 9
- Key functions 10
- Power light key 10
- View key 10
- Exit key 11
- Menu key 11
- Way cursor control key 11
- Accessory bus 12
- Powering up the unit 12
- The menu system 12
- Normal operation 13
- Start up options menu 13
- Pc connect 14
- Simulator 14
- System status 14
- Sensitivity 15
- Sonar x pres 15
- Upper range 15
- Bottom view 16
- Chart speed 16
- Lower range 16
- Sonar menu tab 17
- Zoom level 17
- Beam select 18
- Fish id 18
- Fish sensitivity 19
- Khz balance 19
- Khz sensitivity 19
- Real time sonar rts window 19
- Depth lines 20
- Surface clutter 20
- Max depth 21
- Noise filter 21
- Transducer select 21
- Water type 21
- Alarm tone 22
- Alarms menu tab 22
- Depth alarm 22
- Fish id alarm 22
- Low battery alarm 22
- Setup menu tab 23
- Units depth 23
- Units distance 23
- Units temp 23
- Language 24
- Restore defaults 24
- Triplog reset 24
- Units speed 24
- User mode 24
- Select readouts 25
- Select views 25
- Depth offset 26
- Temp offset 26
- Accessories menu tab 27
- Nmea output 27
- Speed calibration 27
- A connected and functioning transducer will cause the newly started fishing system to go into normal operating mode automatically if when you power up the fishing system it goes into simulator mode automatically even though a transducer is already connected this means that the control head is not detecting the transducer perform the following troubleshooting tasks 28
- Before contacting the humminbird customer resource center please read the following section taking the time to review these troubleshooting guidelines may allow you to solve a performance problem yourself and therefore avoid sending your unit back for repair 28
- Correct any known problems including removing corrosion from the battery terminals or wiring or actually replacing the battery if necessary 28
- Display problems 28
- If your matrix doesn t power up use the installation guide that also comes with it for specific confirmation details making sure that 28
- Matrix defaults to simulator with a transducer attached 28
- Matrix doesn t power up 28
- Problem possible cause 28
- The power cable is properly connected to the matrix control head the power cable is wired correctly with red to positive battery terminal and black to negative terminal or ground the fuse is operational the battery voltage of the power connector is at least 10 volts 28
- There are several main conditions or sources of possible interference that may cause problems with the quality of the information displayed on the control head look in the following table for some symptoms of display problems and possible solutions 28
- Troubleshooting 28
- Using the installation guide that also comes with your fishing system check to make sure that the transducer cable is securely connected to the fishing system reconnect if necessary and power up the fishing system again to see if this fixes the problem replace the non functioning transducer with a known good transducer if available and power up the control head again check the transducer cable replace the transducer if the cable is damaged or corroded 28
- Finding the cause of noise 29
- Matrix fishing system accessories 29
- Specifications 30
- Contact humminbird 31
