Technical Specifications
7
6 Technical Specifications
Table 3 includes the technical specifications:
Table 3: Technical Specifications
1
of the VP-200XLN XGA Line Amplifier / DA
INPUT:
1 XGA on an HD15F connector
OUTPUTS:
2 XGA on HD15F connectors
MAX. OUTPUT LEVEL:
2Vpp
BANDWIDTH (-3dB): 400MHz
DIFF. GAIN: 0.05%
DIFF. PHASE: 0.03°
K-FACTOR: <0.05%
S/N RATIO: 71dB
CONTROLS: Level: –1.5dB to +6.1dB, EQ.: 0 to +7.3dB @ 50MHz
COUPLING: AC/DC
POWER SOURCE: 12 VDC, 95mA
DIMENSIONS: 12cm x 7.15cm x 2.76cm (4.7" x 2.8" x 1.08"), W, D, H
WEIGHT: 0.3 kg. (0.67 lbs.) approx.
ACCESSORIES: Power supply, mounting bracket
OPTIONS: 19" rack adapters RK-T1, RK-T3
1 Specifications are subject to change without notice
