8 VP-2K - Technical Specifications

6 Technical Specifications

INPUTS: Video: 1 UXGA on a 15−pin HD (F) connector;

Audio: 1 audio stereo on RCA connectors

OUTPUTS: Video: 2 UXGA on 15−pin HD (F) connectors;

Audio: 2 audio stereo on RCA connectors

MAX. OUTPUT LEVEL: Video: 2.2Vpp;

Audio: 6.8Vpp

BANDWIDTH (–3dB): Video: 380MHz;

Audio: >100kHz

DIFF. GAIN: 0.03%

DIFF. PHASE: 0.03Deg

K-FACTOR: <0.05%

S/N RATIO: Video: 73dB;

Audio: 89dB

CONTROLS: UXGA: Level: –1.1dB to 6.5dB; EQ.: 0dB to

5.3dB@50MHz;

Audio Level: –50dB to 6.2dB; ID BIT switch; coupling

switches; sync processing (normal or Kr−isp®)

COUPLING: Video: DC/AC selectable;

Audio: input AC; output DC

AUDIO THD + NOISE: 0.064%

AUDIO 2nd HARMONIC: 0.002%

OPERATING TEMPERATURE: 0° to +55°C (32° to 131°F)

STORAGE TEMPERATURE: -45° to +72°C (-49° to 162°F)

HUMIDITY: 10% to 90%, RHL non-condensing

POWER SOURCE: 5V DC, 150mA

DIMENSIONS: 16.2cm x 10.7cm x 4.4cm (6.4" x 4.2" x 1.7" ) W, D, H

WEIGHT: 0.7kg (1.5lbs) approx.

ACCESSORIES: Power supply

OPTIONS: RK-13 19” rack mount

Specifications are subject to change without notice at http://www.kramerelectronics.com
