6 VP-2K - Connecting the VP-2K

5 Connecting the VP-2K

Always switch off the power to each device before connecting it to your

VP-2K. After connecting your VP-2K, connect its power and then

switch on the power to each device.

To connect the VP-2K as illustrated in the example in Figure 2

1. Connect a computer graphics source to the UXGA IN 15-pin HD (F)

connector and to the R and L AUDIO IN RCA connectors.

2. Connect the UXGA OUT 15-pin HD (F) connectors to up to two acceptors

(for example, a display and a projector) and connect the respective R and L

AUDIO OUT RCA connectors to audio acceptors (for example, two

amplifiers with speakers).

When both outputs are not required, connect only the required output and leave the

other output unconnected.

3. Connect the 5V DC power adapter to the power socket and connect the

adapter to the mains electricity (not illustrated in Figure 2

4. If required:

 Check that the SYNC PROC. button is pushed in, to activate the sync

processing

 Adjust the AUDIO LEVEL, the UXGA LEVEL, and/or the UXGA EQ.

(equalization) compensation level

 Set the coupling switch to AC or DC

Note: The VP-2K can also distribute HDTV signals in YPbPr format, using a

breakout cable with the following pinout:

For example, Kramer’s optional VGA to 3RCA breakout cable: C-GM/3RVF (not supplied).

15-pin HD Connector Pinout for HDTV

PIN# YPbPr SIGNAL

1 Pr

2 Y

3 Pb
