Technical Specifications

7 Technical Specifications

Table 4 includes the technical specifications:

Table 4: Technical Specifications

of the VP-12NHD 1:12 + 3 UXGA / CAT5 Distributor

INPUT: 1 UXGA on an HD15F connector

OUTPUTS: 12 UXGA on HD15F connectors

3 RJ-45 OUT connectors

MAX. OUTPUT LEVEL

: UXGA: 1.8Vpp; CAT5: 1.6Vpp

BANDWIDTH (-3dB)

: UXGA: 340MHz; CAT5: 150MHz

DIFF. GAIN: 0.17%

DIFF. PHASE: 0.44°

K-FACTOR: <0.05%

S/N RATIO: 73dB

CONTROLS: Level: -0.8dB to 2.4dB, 2 switches for sync inversion

COUPLING: UXGA: DC; CAT5: AC

POWER SOURCE: 230 VAC, 50 / 60 Hz (115VAC, U.S.A.) 31VA

DIMENSIONS: 19 inch (W), 7 inch (D) 1U (H) rack mountable

WEIGHT: 2.7 kg. (6 lbs.) approx.

ACCESSORIES: Power cord

1 Specifications are subject to change without notice

2 Specifications are shown for the UXGA output, unless stated otherwise

3 The CAT5 output is measured at the TP-120 output, at maximum TP-120 gain of the TP-12N and the TP-120 setup

4 The CAT5 output is measured at the TP-120 output on the TP-12N and the TP-120 setup
