KRAMER: SIMPLE CREATIVE TECHNOLOGY
Your VP-12NHD 1:12 + 3 UXGA / CAT5 Distributor
4
In particular, the VP-12NHD has:
Switches on the underside for ID Bit control and polarity control
1
Three level control trimmers on the underside for red, green, and blue
A video bandwidth that exceeds 300MHz, ensuring that it remains
transparent even at high-resolution UXGA modes
The power connect feature, see section 3.1
In addition, the VP-12NHD is mains fed and housed in a 19" enclosure.
3.4 Recommendations for Achieving the Best Performance
Achieving the best performance means:
Connecting only good quality connection cables, thus avoiding
interference, deterioration in signal quality due to poor matching, and elevated
noise levels (often associated with low quality cables)
Avoiding interference from neighboring electrical appliances that may
adversely influence signal quality, and positioning your VP-12NHD away
from moisture, excessive sunlight and dust
4 Your VP-12NHD 1:12 + 3 UXGA / CAT5 Distributor
This section defines the VP-12NHD 1:12 + 3 UXGA / CAT5 Distributor:
Front and rear panels (see Figure 1 and Table 1)
Underside panel (see Figure 2 and Table 2)
1 Letting you change the polarity of the H and V Sync outputs
