Connecting the VM-1610 and VM-80A

6 Connecting the VM-1610 and VM-80A

Section 6.1 describes how to connect the VM-1610 and section 6.2

describes how to connect VM-80A.

6.1 Connecting the VM-1610 Distribution Amplifier

To connect the VM-1610 in a 1:10 configuration, as shown in

Figure 3, do

the following

1. Connect the input source (for example, a balanced stereo audio player) to

the Channel 1 INPUT terminal block connector.

2. Connect the OUT terminal block connectors to up to 10 acceptors (for

example, balanced stereo audio recorders).

3. Release the MODE button to the 1:10 position.

4. Switch on the VM-1610.

The audio input is distributed to the audio outputs.

Note: The Channel 2 INPUT cannot be distributed to the 10 outputs,

only the Channel 1 INPUT.

5. Adjust the right and left audio levels by turning the CH1 and CH2 LEVEL

trimmers with a small screwdriver.

To connect the VM-1610 in a 2x1:5 configuration, do the following

1. Connect input source 1 (for example, a balanced stereo audio player) to the

Channel 1 INPUT terminal block connector.

2. Connect input source 2 (for example, a balanced stereo audio player) to the

Channel 2 INPUT terminal block connector.

3. Connect the Channel 1 OUT terminal block connectors to up to 5 acceptors

(for example, balanced stereo audio recorders).

4. Connect the Channel 2 OUT terminal block connectors to up to 5 acceptors

(for example, balanced stereo audio recorders).

5. Press in the MODE button to the 2x1:5 position.

6. Switch on the VM-1610.

The Channel 1 audio inputs are distributed to the Channel 1 audio outputs.

The Channel 2 audio inputs are distributed to the Channel 2 audio outputs.

1 Switch OFF the power on each device before connecting it to your VM-1610. After connecting your VM-1610, switch on

its power and then switch on the power on each device
