VM-3HN - Connecting the VM-3HN

4 Connecting the VM-3HN

Always switch off the power to each device before connecting it to your

VM-3HN. After connecting your VM-3HN, connect its power and then

switch on the power to each device.

Connect the VM-3HN as illustrated in the example in Figure 2:

1. Connect an HDMI input source (for example, a Blu-ray player) to the HDMI

IN connector.

2. Connect the three OUTPUT connectors to up to three HDMI acceptors, as

follows:

Not all outputs need to be connected.

 HDMI OUT 1 connector to HDMI acceptor 1 (for example, display 1)

 HDMI OUT 2 connector to HDMI acceptor 2 (for example, display 2)

 HDMI OUT 3 connector to HDMI acceptor 3 (for example, display 3)

3. Connect the 5V DC power adapter to the power socket unit and then

connect the adapter to the mains electricity (not shown in Figure 2).

The ON LED lights.
