Technical Specifications

6 Technical Specifications

Table 2 includes the technical specifications:

Table 2: Technical Specifications

of the VP-32K 3x1 PC/ Audio Switcher

INPUTS: 3 UXGA on 15-pin HD connectors

3 balanced stereo audio 10k on 5-PIN terminal block connectors

OUTPUTS: 2 UXGA on 15-pin HD connectors

2 balanced stereo audio on 5-PIN terminal block connectors

MAX. OUTPUT LEVEL: VIDEO: 2.3Vpp AUDIO: 6.8Vpp

BANDWIDTH (-3dB): VIDEO: 420MHz AUDIO: >100kHz

DIFF. GAIN: 0.03%

DIFF. PHASE: 0.03 deg

K-FACTOR: <0.05%

S/N RATIO: VIDEO: 72dB @5MHz AUDIO: 88dB @1kHz

CROSSTALK (all hostile):

VIDEO: –54dB AUDIO: –77dB @1kHz

CONTROLS: Front panel push buttons, contact closure remote control (on rear

panel)

COUPLING: VIDEO: DC AUDIO: Input: AC; Output: DC

AUDIO THD + NOISE: 0.009%

AUDIO 2nd HARMONIC:

0.001%

POWER SOURCE: 5V DC 210mA

DIMENSIONS: 21.46cm x 18cm x 4.36cm (8.45" x 7" x 1.72") W, D, H.

WEIGHT: 1.1kg (2.4lbs) approx.

ACCESSORIES: Power supply

OPTIONS: 19" rack adapters

1 Specifications are subject to change without notice
