4 Connecting the VS-41HC

Always switch off the power to each device before connecting it to your

VS-41HC. After connecting your VS-41HC, connect its power and then

switch on the power to each device.

To connect the VS-41HC as illustrated in the example in

Figure 2:

1. If required, acquire the EDID (see Section

5.1).

2. Connect the OUTPUT HDMI connector to an HDMI acceptor (for example,

an LCD display).

3. Connect the HDMI sources as follows:

You do not have to connect all the HDMI sources.

 A multimedia player to INPUT 1

 A set top box to INPUT 2

 A DVD player to INPUT 3

 A DVD player to INPUT 4

4. Connect the 12V DC power adapter to the power socket and connect the

adapter to the mains electricity (not shown in

Figure 2).

Press an INPUT SELECTOR button (from 1 to 4) to choose which HDMI input to

route to the output.
