Overview

3 Overview

The 6241HDxl 4x1 3G HD-SDI Switcher is a high-performance switcher for 3G

HD-SDI serial digital video signals. It takes any one of four 3G HD-SDI inputs,

applies reclocking and equalization, and outputs the signal to one 3G HD-SDI

output.

The 6241HDxl features:

• A maximum data rate up to 2.97Gbps

• HDTV compatibility

• SMPTE 259M, 344M, 292M and 424M compliance

• Adjustment-free operation

• Automatic equalization for losses on 75Ω coaxial cable

• Reclocking the input signal to provide a low-jitter, serial digital output

• 8-bit and 10-bit video operation with automatic word length recognition

• Unmodified transmission of all signal information (including embedded

information) from the inputs to the output

To achieve the best performance:

• Use only good quality connection cables

• Avoid interference from neighboring electrical appliances that may

adversely influence signal quality and position your Kramer 6241HDxl

away from moisture, excessive sunlight and dust

to avoid interference, deterioration

in signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables).

1 Up to hundreds of meters of cable (depending on the cable quality and the video standard)

2 Available from Kramer Electronics on our Web site at

http://www.kramerelectronics.com
