Secure DisplayPort KVM Switch User Manual
Rear Panel Features –K502
Console Area
1 - Audio console output 3.5 mm stereo jack
2 - USB Keyboard & Mouse jacks
3 – Console DisplayPort video input jack & diagnostic LED
1
2
3
Computer Area
4 - Computer USB Keyboard & Mouse jack
5 - Computer audio input jack 3.5mm stereo
6 - Computer DP video input jack
General
7 - DC Power input jack – barrel type
4
5
6
