RC-52A – Installing the Configuration Software 9

5 Installing the Configuration Software

Download the K-Config configuration software from our Web site and install it (refer

to the K-Config guide).

5.1 13BConfiguring the RC-52A Buttons

To configure the RC-52A buttons, refer to the relevant Configuration guide.

Before you configure the RC-52A buttons:

1. Connect the RC-52A to your PC with the USB cable.

There is no need to connect the RC-52A to a power supply for configuration since

power is supplied over the USB cable.

2. Open the Configuration program.

3. Follow the instructions in the Configuration guide to configure the RC-52A

buttons.

5.2 14BLocking and Unlocking the RC-52A

You can lock the front panel buttons by pressing a predefined button on the front

panel. Pressing the lock button initiates a macro sequence (a series of commands,

which can include the dimming of the lights, shutdown of the A/V machines and so

on).

You can unlock the front panel buttons by pressing a predefined sequence of four

buttons.

The locking procedure can be configured as a part of the timeout or scheduling

event macros.

You can consult the installer of your unit regarding the specific

configuration of the locking and unlocking feature on your system.
