RC-76R/RC-78R - Connecting the RC-76R/RC-78R

4 Connecting the RC-76R/RC-78R

Always switch off the power to each device before connecting it to your

RC-76R/RC-78R. After connecting your RC-76R/RC-78R, connect its

power and then switch on the power to each device.

To connect the RC-76R/RC-78R as illustrated in the example in Figure 2:

1. Connect the IR outputs as follows:

 Connect an IR emitter to IR OUTPUT 1 and attach the emitter to the

DVD player 1

 Connect an IR emitter to IR OUTPUT 2 and attach the emitter to the

DVD player 2

2. Connect the RS-232 ports (see Section 4.1) as follows:

 Connect RS-232 port 1 to the projector

 Connect RS-232 port 2 to the plasma display

3. Connect the RELAY terminal block connectors as follows:

 Connect RELAY C and 1 to the screen

 Connect RELAY C and 2 to the lighting system

4. Connect the GPI/O 1 port to a motion detector.

5. Connect the Ethernet port to a network.
