RC-76M/ RC-712M - Overview

3 Overview

The RC-76M and RC-712M are six and twelve−button configurable room

controllers for multimedia rooms. They control audio components, video

components and other room facilities such as lights and screens. They are

designed to be installed in compatible Merten System M on-wall boxes (frame and

housing).

RC-76M/RC-712M features:

 6/12 configurable buttons - RGB backlit, front panel buttons, configured

using the K−Config configuration software

 1 GPI/O port that can be configured by K−Config configuration software as a

digital input, digital output or analog input for interfacing with a variety of

devices such as sensors, switches, LEDs, or relays

 Kramer Site-CTRL compatibility for network remote control and management

over the Ethernet port

 2 bidirectional RS-232 ports for the control of AV equipment such as

projectors, LCD and PDP displays, power amplifiers, switchers and scalers

 2 relay contact closure ports for the control of other room items related to an

AV system, such as, raising and lowering drapes, a screen or a projector

 2 IR control ports with an IR learning receiver on the front panel that learns

commands from any IR remote

 1 RS-485 port

 A K-NET™ control channel that connects compatible user interfaces,

supplies power and controls data over a single cable

 A USB port located on the front panel to connect to a computer for firmware

upgrade or for uploading the configuration file

 Flexible control - via Ethernet and K−NET

 Wall Plate Size - 2 gang EU, Merten compatible
