8 FC-31xl - Technical Specifications
5 Technical Specifications
INPUT: 1 UXGA on a 15-pin HD connector
OUTPUT: 1 DVI (On a DVI-I connector. Note that only a DVI-D
signal is available on the DVI connector), 1.2Vpp on a
DVI Molex 24-pin female connector; DDC signal 5Vpp
(TTL)
SUPPORTED RESOLUTIONS: 640x480 @60Hz/72Hz/75Hz/85Hz; 720x400
@70Hz/85Hz;
800x600 @56Hz/60Hz/72Hz/75Hz/85Hz; 848x480
@60Hz; 1024x768 @60Hz/72Hz/75Hz/85Hz; 1152x864
@75Hz; 1280x768 @60Hz (RB)/75Hz/85Hz; 1280x800
@60Hz; 1280x960 @60Hz/85Hz; 1280x1024
@60Hz/75Hz/85Hz; 1360x768 @60Hz; 1400x1050
@60Hz(RB)/75Hz; 1440x900 @60Hz; 1440x1050
@60Hz; 1600x1200 @60Hz; 1680x1050 @60Hz;
1920x1080 @60Hz; 1920x1200 @60Hz(RB)
DVI BANDWIDTH: 1.65GHz
CONTROLS: DIP-switches
COUPLING: DC
POWER SOURCE: 12V, 180mA
OPERATING TEMPERATURE: 0° to +55°C (32° to 131°F)
STORAGE TEMPERATURE: -45° to +72°C (-49° to 162°F)
HUMIDITY: 10% to 90%, RHL non-condensing
DIMENSIONS: 10.7cm x 4.0cm x 15.9cm (4.20" x 1.59" x 6.26") W, D, H
WEIGHT: 0.15kg. (0.55lbs.) approx.
ACCESSORIES: Power supply
OPTIONS: RK−1 19" rack adapter.
Specifications are subject to change without notice at Uhttp://www.kramerelectronics.comU
