FC-31xl - Overview 3
3 Overview
The Kramer FC−31xl is a high−performance format converter for computer
graphics signals with resolutions up to and including WUXGA. The unit converts a
computer graphics input to a DVI−D output.
The following table lists the resolutions supported by the FC-31xl.
Resolution
Frequency [Hz]
Resolution
Frequency [Hz]
640x480
60, 72, 75, 85
1280x1024
60, 75, 85
720x400
70, 85
1360x768
60
800x600
56, 60, 72, 75, 85
1400x1050
60 (RB), 75
848x480 60
1440x900
60
1024x768
60, 72, 75, 85
1440x1050
60
1152x864
75
1600x1200
60
1280x768
60 (RB - reduced
blanking), 75, 85
1680x1050 60
1280x800
60
1920x1080
60
1280x960
60, 85
1920x1200
60 (RB)
In particular, the FC-31xl:
• Includes DIP-switches that let you adjust the horizontal position, the vertical
position, and/or the sharpness of the image
• Is 12V DC fed
