8
FC-69 - Operating the FC-69
6 Operating the FC-69
6.1 Setting the DIP-switches
The following table describes the functions of the DIP-switches.
A DIP-switch that is up is off; one that is down is on. Default is up (off).
#
Mode/Preset
Off
On
1
HDCP
Pass HDCP (default)
2
Audio source
Analog
3
EDID
Pass the EDID (default)
4
Color depth
Pass (default)
5
Audio
Pass (default)
6
De-embed
ARC
Note: When DIP-switch 2
is on, ARC does not work
7
Sleep
Off
8
Time Out, (effective
only when DIP-
switch 7 is off)
5 Seconds
6.2 LED Status
The following table describes the status of the LEDs.
LED
Off
On
HDCP
Input signal without HDCP
Input signal with HDCP
Out
Output disconnected
Output connected
In
Input invalid
Input valid
On
No power
Power connected
6.3 Audio Extraction
If the source signal contains uncompressed, LPCM, multi-channel audio, the
analog audio port only outputs the front-left and front-right channels.
If the source signal contains compressed audio, the analog output is muted.
Note: If an ARC source signal contains compressed audio, the analog output
transmits unclear audio.
